D&M Shields – Fusion 360

As of 4/4/20, we are busy 3d printing our rigid shield design, efficiently hacked into its current form by Bret here at D&M. click here to visit or download the Fusion files!

The flat, snap-fit nature of this design can easily be lasercut as well- the varied depths of the printed model are just an effort to minimize excess plastic and print time.

More to come on the laser side of things- in addition to the massive time savings- like <20 seconds vs. >3 hours per shield- we can use far cheaper and varied materials with the addition of our sterilizable and durable UV resins and coatings. Similarly, lasercut stock + resin offers the possibility quick adaptation and derivative design, such as [flexible](https://a360.co/2UFKRHM) UV cured forms.

ppe & whatnot

Yep, we too are busy cooking up protective medical devices.......

¯_(ツ)_/¯

& whatnot:

Prototyping bits, bobs for an ada motorsports startup-

ADA auto prototyping

Fast Pi camera stand sketch:

Quick pass at a low friction filament spool holder for some very fragile materials:

Some GDAL shell macros from R instead of rgdal

also here on github

it's not R sacrilege if nobody knows

Even the little stuff benefits from some organizational scripting, even if it’s just to catalog one’s actions. Here are some examples for common tasks.

Get all the source data into a R-friendly format like csv. ogr2ogr has a nifty option -lco GEOMETRY=AS_WKT (Well-Known-Text) to keep track of spatial data throughout abstractions- we can add the WKT as a cell until it is time to write the data out again.

# define a shapefile conversion to csv from system's shell:
sys_SHP2CSV <- function(shp) {
  csvfile <- paste0(shp, '.csv')
  shpfile <-paste0(shp, '.shp')
  if (!file.exists(csvfile)) {
    # use -lco GEOMETRY to maintain location
    # for reference, shp --> geojson would look like:
    # system('ogr2ogr -f geojson output.geojson input.shp')
    # keeps geometry as WKT:
    cmd <- paste('ogr2ogr -f CSV', csvfile, shpfile, '-lco GEOMETRY=AS_WKT')
    system(cmd)  # executes command
  } else {
    print(paste('output file already exists, please delete', csvfile, 'before converting again'))
  }
  return(csvfile)
}

Read the new csv into R:

# for file 'foo.shp':
foo_raw <- read.csv(sys_SHP2CSV(shp='foo'), sep = ',')

One might do any number of things now, some here lets snag some columns and rename them:

# rename the subset of data "foo" we want in a data.frame:
foo <- data.frame(foo_raw[1:5])
colnames(foo) <- c('bar', 'eggs', 'ham', 'hello', 'world')

We could do some more careful parsing too, here a semicolon in cell strings can be converted to a comma:

# replace ` ; ` to ` , ` in col "bar":
foo$bar <- gsub(pattern=";", replacement=",", foo$bar)

Do whatever you do for an output directory:

# make a output file directory if you're into that
# my preference is to only keep one set of output files per run
# here, we'd reset the directory before adding any new output files
redir <- function(outdir) {
  if (dir.exists(outdir)) {
    system(paste('rm -rf', outdir))
  }
  dir.create(outdir)
}

Of course, once your data is in R there are countless "R things" one could do...

# iterate to fill empty cells with preceding values
for (i in 1:length(foo[,1])) {
  if (nchar(foo$bar[i]) < 1) {
    foo$bar[i] <- foo$bar[i-1]
  }
  # fill incomplete rows with NA values:
  if (nchar(foo$bar[i]) < 1) {
    foo[i,] <- NA
  }
}

# remove NA rows if there is nothing better to do:
newfoo <- na.omit(foo)

Even though this is totally adding a level of complexity to what could be a single ogr2ogr command, I've decided it is still worth it- I'd definitely rather keep track of everything I do over forget what I did.... xD

# make some methods to write out various kinds of files via gdal:
to_GEO <- function(target) {
  print(paste('converting', target, 'to geojson .... '))
  system(paste('ogr2ogr -f', " geojson ",  paste0(target, '.geojson'), paste0(target, '.csv')))
}

to_SHP <- function(target) {
  print(paste('converting ', target, ' to ESRI Shapefile .... '))
  system(paste('ogr2ogr -f', " 'ESRI Shapefile' ",  paste0(target, '.shp'), paste0(target, '.csv')))
}

# name files:
foo_name <- 'output_foo'

# for table data 'foo', first:
write.csv(foo, paste0(foo_name, '.csv'))

# convert with the above csv:
to_SHP(foo_name)

Cheers!
-Jess

When it must be Windows….

Added here on Github

Regarding Windows-specific software, such as ArcMap:

Remote Desktop:
The greatest solution I've settled on for ArcMap use continues to be Chrome Remote Desktop, coupled with an IT Surplus desktop purchased for ~$50. Once Chrome is good to go on the remote Windows computer, one can operate everything from a web browser from anywhere else (even reboot and share files to and from the remote computer). While adding an additional, dedicated computer like this may not be possible for many students, it is certainly the simplest and most dependable solution.

VirtualBox, Bootcamp, etc:
Oracle's VirtualBox is a longstanding (and free!) virtualization software. A Windows virtual machine is vastly preferable over Bootcamp or further partition tomfoolery.
One can start / stop the VM only when its needed, store it on a usb stick, avoid insane pmbr issues, etc.

  • Bootcamp will consume at least 40gb of space at all times before even attempting to function, whereas even a fully configured Windows VirtualBox VDI will only consume ~22gb, and can be moved elsewhere if not in use.
  • There are better (not free) virtualization tools such as Parallels, though any way you slice it a dedicated machine will almost always be a better solution.

Setup & Configure VirtualBox:

There are numerous sites with VirtualBox guides, so I will not go into detail here.

Extra bits on setup-

  • Guest Additions are not necessary, despite what some folks may suggest.

  • Dynamically Allocated VDI is the way to go as a virtual disk. There is no reason not to set the allocated disk size to the biggest value allowed, as it will never consume any more space than the virtual machine actually needs.

  • Best to click through all the other machine settings just to see what is available, it is easy enough to make changes over time.

  • There are many more levels of convoluted not worth stooping to, ranging from ArcMap via AWS EC2 or openstack to KVM/QEMU to WINE. Take it from me

xD

Weekend Design: Laser-cuttable FPGA Demo Enclosure

Link- Digilent Xilinx Genesys 2 FPGA Reference (Display is a panel from New Haven)
Link to A360 Page
